Injectable Dry Powder Vial Filling Line Machine

Injectable Dry Powder Vial Filling Line Machine

400000.00 Onwards INR/Unit

Product Details:

  • Material Mild Steel, Stainless Steel
  • Feature Heavy Duty Machine
  • Automatic Grade Automatic
  • Control System PLC Control
  • Drive Type Electric
  • Warranty 01 year
  • Supply Ability : 10 Unit Per Day
  • Click to view more
X

Price And Quantity

  • 400000.00 Onwards INR/Unit
  • 01 Unit

Product Specifications

  • Automatic
  • 01 year
  • Mild Steel, Stainless Steel
  • Heavy Duty Machine
  • PLC Control
  • Electric

Trade Information

  • Cash in Advance (CID)
  • 10 Unit Per Day
  • 2-3 Week
  • Africa, Middle East, Western Europe, Eastern Europe, South America, North America, Central America, Australia, Asia
  • All India

Product Description

We are a profound manufacturer of Injectable Dry Powder Vial Filling Line Machine in the market. It is a very efficient machine used for filling up the dry powder in to the vials. It also places a rubber stopper on the top of the vial, once it is filled with the powder. Injectable Dry Powder Vial Filling Line Machine can be availed from us at competitive rates.

Injectable Dry Powder Filling Machine is suitable for filling dry syrup powder and granules in different type and shape of bottles with max speed of 240 bottles per minute depending on filling volume, type of powder and bottle size.

Sterilized dry container are fed through/guided on Delrin flat conveyor belt at required speed for placement below powder wheel. The sterilized powder stored in hopper is agitated by pair of mechanical agitators. The powder wheel having eight ports rotates at the pre-determined speed. Precise volume of powder is sucked in to the port of powder wheel during vacuum, as per piston length different fill size can be achieved. The time dose of Compressed air (Nitrogen Gas), flushes out powder from the port of powder wheel into the container one by one. Filled containers moves further for Stoppering operation. (Different grooves separator can be used which depends on the container diameter or multiple dosing systems). The sterilized, rubber stoppers stored in the vibrator bowl moves to vibratory bowl and is stacked vertically in the rubber stopper chute. The container is hold firmly between pair or timing belt to pick up rubber stopper from exit end of the chute. Further the container is passed between two pressing rollers for tight fit/fixing of rubber stopper.

SALIENT FEATURES:



  • All the contact parts are made of S.S 316 and are easily removable for Autoclaving / Sterilization.
  • Individual drives for Infeed and Outfeed turntables. A/C Frequency Drive for speed control.
  • Safety clutch system to avoid vial breakage.
  • Pure Air Filters for Air and Vacuum.
  • Online Pre - Media Filling System. Pre & Post Gassing System and Multiple Dosing System.



OPTIONAL ACCESSORIES:



  • Canister Based Powder Loading System.
  • Laminar Air Flow System.
  • PLC with Touchscreen HMI.
  • Dust Extraction Unit.
  • Swing Type Conveyor.



TECHNICAL SPECIFICATIONS:

Model

PPF-IDP 120

PPF-IDP 240

Direction

Left to Right

Left to Right

Capacity/Min (For Single Dose)

Up to 120 Fills

Up to 240 Fills

Vial Diameter (In mm)

25 to 45 max.

25 to 45 max.

Height (In mm)

75 max.

75 max.

Rubber Stopper (In mm)

20 dia.

20 dia.

Electrical Specifications

1.00 HP For Main Drive.

0.50 HP For Conveyor motor 5 AMP Coils for vibratory

2.00 HP For Main Drive.

0.50 HP For Conveyor motor 5 AMP Coils for vibratory

Fill Capacity

60mg to 1.5gm Single Dose (with Change Parts) Fill range depending upon vial opening and bulk density of powder. Under controlled Environment (i.e., Humidity less than 25%)

Accuracy

1% depending upon consistency and uniformity of bulk density of Injectable powder

Pneumatic Air

Filtered, oil free, sterile low-pressure AIR at 2 kg/cm2 (2/3 bar)

Vacuum line

20mmHG. (Pump will be supplied by US .)

Height of Conveyor (In mm)

Adjustable from 850 To 910

* Depends on size of Container, fill size, Neck diameter of container, and nature of powder etc.

** We can supply as per customer requirements.
